Wellhead, Conductor and Casing Fatigue – Causes and Mitigation
EVENT: DOT
1 Nov 2012
Drilling operations for subsea wells are typically carried out using drilling risers with subsea BOP stacks deployed from mobile drilling units. The drilling risers are subject to wave-induced motions both from vessel motions and direct wave loading, as well as vortex-induced vibration (VIV) due to current flow past the riser.
The motions are transferred down the riser to the wellhead, conductor and casing system and can cause fatigue issues at critical connectors and welds. The potential for severe fatigue loading of the wellhead system has increased over the last few years due to the use of 5th and 6th generation drilling vessels with larger BOP’s and considerably longer well operations, required to maximise output.
Equipment selection is often based on what has been used on previous wells and is not always application specific. Analyses done during the conceptual design stage often focuses on the drilling riser and the fatigue performance of the wellhead and conductor are often overlooked.
This paper describes the parameters that influence the riser motions transferred to the wellhead, conductor and casing system, and highlights those that are most damaging to fatigue performance. The options available to mitigate the fatigue issues through improved equipment configuration and specification are also discussed, together with various monitoring and fatigue tracking strategies to address these potential concerns.
Authors
Tze King Lim
Technical Manager
Tze King Lim
Technical Manager
Insights

Elizabeth Tellier
Director, Australia

About
Elizabeth is the director of 2H’s Perth office. She holds a bachelor’s degree in Mechanical Engineering from Texas A&M University and has 17 years’ experience in the oil and gas industry with various types of riser design, subsea structural monitoring systems and riser integrity management. In 2010 Elizabeth relocated to Perth from 2H Houston to start a local office with the goal of supporting the growing subsea market in WA. Major project involvement includes BP Subsea & Riser Integrity Management , Anadarko Caesar Tonga Freestanding Riser Pre-FEED and FEED, developing 2H Perth’s drilling riser and conductor capability and delivering various subsea structural monitoring solutions to clients in Australia.
